Get your special offer on ÖLFLEX® SOLAR XLWP and other selected solar products until 30 April for the safe cabling of solar systems.

ÖLFLEX® SOLAR XLWP: electron beam cross-linked solar cable with optimized performance in water

ÖLFLEX®SOLAR XLWP cables are weather-, abrasion- and UV-resistant photovoltaic cables. Optimized cable design allows a constant high contact resistance to be achieved when stored in water.

These halogen-free, double-insulated and cross-linked solar cables are suitable for permanent outdoor use to connect grounded and ungrounded photovoltaic systems. They are used both for wiring solar modules together and for connecting the individual module rows and the inverter.

Part number Article name
1023601 ÖLFLEX® SOLAR XLWP 1x4 WH/BK
1023625 ÖLFLEX® SOLAR XLWP 1X4 WH/BK-BU
1023621 ÖLFLEX® SOLAR XLWP 1x4 WH/BK-RD
1023602 ÖLFLEX® SOLAR XLWP 1x6 WH/BK
1023626 ÖLFLEX® SOLAR XLWP 1X6 WH/BK-BU
1023622 ÖLFLEX® SOLAR XLWP 1x6 WH/BK-RD



H1Z2Z2-K cross-linked solar cable

Cross-linked solar cable for long-lasting, weather-resistant use in photovoltaic systems.

Areas of application:
- PV systems with DC system voltage up to max. 1800 V.
- For the cabling of solar modules as well as for the connection of module rows with the inverter
- Flexible or building-integrated PV systems

Part number Article name
1023759 H1Z2Z2-K 1X4 BK
1023760 H1Z2Z2-K 1X6 BK
1023761 H1Z2Z2-K 1X10 BK
1023774 H1Z2Z2-K 1X4 RD
1023775 H1Z2Z2-K 1X6 RD
1023776 H1Z2Z2-K 1X10 RD
1023789 H1Z2Z2-K 1X4 BU
1023790 H1Z2Z2-K 1X6 BU
1023791 H1Z2Z2-K 1X10 BU



EPIC® SOLAR 4 Plus

Connector system for weatherproof wiring of photovoltaic systems up to 1,500V.
The plug has a market standard 4 mm contact with double snap-in hook. Compatible with the Multi Contact MC 4 system according to IEC 61076-1. Crimp connection - for wire cross-sections up to 10 mm².

The 44428255 set consists of
10 x EPIC SOLAR 4PLUS M 4 6mm² with contacts
10 x EPIC SOLAR 4PLUS F 4 6mm² with contacts

Part number Article name
44428236 EPIC® SOLAR 4Plus F 4  6mm²
44428235 EPIC® SOLAR 4Plus M 4  6mm²
44428255 EPIC® SOLAR EPIC SOLAR 4PLUS M+F 4 6mm² SET





Suitable accessories

Part number Article name
21920120 UNIVERSAL STRIP SOLAR
11147000 EPIC® HAND CRIMP TOOL FOR SINGLE CONTACTS
44428992 EPIC® SOLAR Tool CSC Die 4mm²
44428993 EPIC® SOLAR Tool CSC Die 6mm²
44428994 EPIC® SOLAR Tool CSC Loc 4, 6mm²
